This year, the DockerConEU took place in Copenhagen, this event was a great opportunity to learn more about containers evolution. Through a lot of very interesting talks and two keynotes (described here), we noted the following main events in the container ecosystem:
- Kubernetes integration into Docker-Enterprise defines it as the main actor in the container orchestration domain.
- The three big players (Google, Microsoft, Docker) work together to improve the container environment.
- The Cloud Native Computing Foundation (CNCF) is the main actor in the OpenSource communities around containers with projects like Kubernetes, Prometheus, Fluentd, …
All these changes encourage us to focus on CNCF container standardization.
The first container standard was published by the Open Container Initiative, and the implementation reference called
runc is used everywhere.
runc is a great product, unfortunately, some features are missing to become a full-featured alternative to Docker:
- pulling images
- images storage & container layers
- troubleshooting containers with a
- logs storing
- networks creation
- port forwarding
Based on this situation, people from the CNCF started working on a new standard that will include the features listed above. The standard is called Container Runtime Interface (CRI) and several implementations are available:
- dockershim: to support the old Docker solution
- cri-containerd: to support Docker Containerd
- cri-o: a new container solution created by RedHat
- rkt: to support CoreOS Rocket
- frakti: to run containers inside Virtual Machines
A standard is only successful if the implementations are interchangeable. It’s a good news, switching between CRI-O and CRI-Containerd seems possible.
In the example below, we are going to use crictl, the command line interface for CRI, to pull an image and start a container on two different CRI implementations without requiring any change.
The full installation steps are not described in this article, but you can find them in this gist.
VM 1 - Start Containerd and CRI-Containerd
$ containerd & $ cri-containerd & $ echo "runtime-endpoint: /var/run/cri-containerd.sock" > /etc/crictl.yaml
VM 2 - Start CRI-O
$ crio & $ echo "runtime-endpoint: /var/run/crio/crio.sock" > /etc/crictl.yaml
Both VM - Pull the redis images
$ crictl pull redis:alpine Image is update to date for sha256:ba3df185d5ea4cae3b5da690301605ac96199732bab4edf46f7bafec43dbcb1f $ crictl images IMAGE TAG IMAGE ID SIZE docker.io/library/redis alpine ba3df185d5ea4 10.1MB
Both VM - Start container
CRI needs two configuration files, one for the pod and one for the container. We are going to use the following test examples:
These configurations are coming from the CRI-O repository but also work with CRI-Containerd
$ POD_ID=$(crictl runs test/testdata/sandbox_config.json) $ CONTAINER_ID=(crictl create POD_ID test/testdata/container_redis.json test/testdata/sandbox_config.json) $ crictl start $CONTAINER_ID d94bf519cf7ffcacf6c689250592d0718b98d7a030d73329349d29dc560e4998 $ crictl ps $CONTAINER_ID CONTAINER ID IMAGE CREATED STATE NAME ATTEMPT d94bf519cf7ff redis:alpine 5 seconds ago CONTAINER_RUNNING podsandbox1-redis 0
It’s not a 100% proof that interoperability between implementations will work but it’s a good sign that it’s coming.
CRI provides the basic features available in Docker:
NAME: crictl - client for CRI USAGE: crictl [global options] command [command options] [arguments...] VERSION: 0.2.0 COMMANDS: attach Attach to a running container create Create a new container exec Run a command in a running container version Display runtime version information images List images inspect Display the status of a container inspecti Return the status of an image inspects Display the status of a sandbox logs Fetch the logs of a container port-forward Forward local port to a sandbox ps List containers pull Pull an image from a registry runs Run a new sandbox rm Remove a container rmi Remove an image rms Remove a sandbox sandboxes List sandboxes start Start a created container info Display information of the container runtime stop Stop a running container stops Stop a running sandbox update Update a running container config Get and set crictl options stats List container(s) resource usage statistics help, h Shows a list of commands or help for one command
Great solution to be continued
Container standardization progressed substantially, nevertheless additional work is still needed to reach vendor independence particularly from Docker:
- the Dockerfile and the
docker buildprocess was part of the success of Docker. Unfortunately, the Dockerfile is not standardized, alternative implementations RedHat buildah and Docker buildkit are not 100% interchangeable.
- the image signature is currently a nightmare: Docker signatures based on the Notary project are not recognized by RedHat CRI-O and RedHat Registry signatures are not recognized by Containerd and Docker. Recently, Docker moved the Notary project to the CNCF, we hope it will build the path to a Container Image Signature Interface that would allow to largely improve the current situation.
